Stainless steel weaven wire mesh

Stainless steel weaven wire mesh

Application:

● Window screen

● Screening & Sieving

● Architecture

● Security Mesh

● Chemical industry

● Petroleum

● Medicine

● Electronics

● Printing

Inquire Now Next Product

PRODUCT DESCRIPTION

Weaving method:

● Plain ----from 0.5X0.5mesh to 635X635 mesh.

● Twill---20x20mesh to 400x400mesh

● Dutch weave 10X64mesh to 400X2800mesh.

● Lock Crimp & Inter Crimp Weave,

Benifits:

● Corrosion resistance

● Anti-acid and alkali

● Anti-high temperature

● Good filter performance

● Long using life

Application:

● Window screen

● Screening & Sieving

● Architecture

● Security Mesh

● Chemical industry

● Petroleum

● Medicine

● Electronics

● Printing

Specification:

Micron	Mesh	SWG	Apt (mm)	Wire (mm)	Width (mm)	Length (Mtrs)	Grade	Weave	Open %
26	500	50	0.026	0.025	1220	30	316	TW	26
34	400	49	0.034	0.03	1220	30	316	TW	28
43	325	48.5	0.043	0.035	1220	30	316	TW	30
45	300	48	0.045	0.04	1220	30	316	TW	28
62	250	48	0.062	0.04	1220	30	316	TW	37
77	200	47	0.077	0.05	1220	30	316	PW	37
91	180	47	0.091	0.05	1220	30	316	PW	42
104	150	45.5	0.104	0.065	1220	30	316	PW	38
104	150	45.5	0.104	0.065	1220	2	316	PW	38
132	120	44	0.132	0.08	1550	30	316	PW	39
154	100	42	0.154	0.1	1245	30	316	PW	37
154	100	42	0.154	0.1	1550	30	316	PW	37
193	80	39	0.193	0.125	1245	30	316	PW	37
193	80	39	0.193	0.125	1245	2	316	PW	37
193	80	39	0.193	0.125	1550	30	316	PW	37
223	70	38	0.223	0.014	1550	30	316	PW	38
250	60	37	0.25	0.174	1245	30	316	PW	34
250	60	37	0.25	0.174	1550	30	316	PW	34
318	50	36.5	0.318	0.19	1245	30	316	PW	39
318	50	36.5	0.318	0.19	1550	30	316	PW	39
415	40	34	0.415	0.22	1245	30	316	PW	43
415	40	34	0.415	0.22	1550	30	316	PW	43
547	30	30	0.547	0.3	1245	2	304	PW	42
547	30	30	0.547	0.3	1245	30	316	PW	42
547	30	30	0.547	0.3	1550	30	304	PW	42
567	30	32	0.567	0.28	1245	30	304	PW	45
608	24	26	0.608	0.45	1550	30	304	PW	35
650	24	26	0.65	0.19	1550	30	304	PW	60
710	20	24	0.71	0.56	1550	30	304	PW	31
758	24	30	0.758	0.3	1245	30	304	PW	51
820	20	26	0.82	0.45	1245	30	304	PW	42
820	20	26	0.82	0.45	1245	30	316	PW	42
820	20	26	0.82	0.45	1550	30	304	PW	42
920	20	28	0.92	0.35	1245	30	304	PW	52
920	20	28	0.92	0.35	1245	30	316	PW	52
	16	24	1.03	0.056	1245	30	304	PW	42
	16	24	1.03	0.056	1245	30	316	PW	42
	16	24	1.03	0.056	1550	30	304	PW	42
	16	24	1.03	0.056	1550	30	316	PW	42
	16	26	1.14	0.45	1245	30	304	PW	51
	16	26	1.14	0.45	1550	30	304	PW	51
	26	28	1.24	0.35	1245	30	304	PW	61
	26	28	1.24	0.35	1550	30	304	PW	61
	14	24	1.25	0.56	1245	30	304	PW	48
	14	24	1.25	0.56	1550	30	304	PW	48
	12	22	1.41	0.71	1245	30	304	PW	44
	12	22	1.41	0.71	1550	30	304	PW	44
	12	24	1.56	0.56	1245	30	304	PW	54
	12	24	1.56	0.56	1245	2	316	PW	54
	8	16	1.58	1.6	1245	30	316	PW	25
	10	20	1.64	0.9	915	30	304	PW	42
	10	20	1.64	0.9	1245	30	304	PW	42
	10	20	1.64	0.9	1245	30	316	PW	42
	10	20	1.64	0.9	1245	2	316	PW	42
	10	20	1.64	0.9	1550	30	304	PW	42
	10	20	1.64	0.9	1550	30	316	PW	42
	12	26	1.67	0.45	1245	30	304	PW	62
	12	26	1.67	0.45	1245	30	316	PW	62
	12	26	1.67	0.45	1550	30	316	PW	62
	9	20	1.92	0.9	1550	30	304	PW	46
	8	18	1.98	1.2	1245	30	304	PW	39
	8	18	1.98	1.2	1550	30	304	PW	39
	10	24	1.98	0.56	1245	30	316	PW	61
	10	24	1.98	0.56	1550	30	316	PW	61
	10	26	2.09	0.45	1245	30	304	PW	68
	10	26	2.09	0.45	1245	2	304	PW	68
	10	26	2.09	0.45	1550	30	304	PW	68
	8	20	2.28	0.9	1245	30	304	PW	51
	8	22	2.47	0.71	1245	30	304	PW	60
	8	22	2.47	0.71	1550	30	304	PW	60
	6	16	2.63	1.6	1245	30	316	PW	39
	6	18	3.03	1.2	1245	30	304	PW	51
	6	18	3.03	1.2	1245	30	316	PW	51
	6	18	3.03	1.2	1550	30	304	PW	51
	6	20	3.33	0.9	1245	30	304	PW	62
	6	20	3.33	0.9	1550	30	304	PW	62
	5	16	3.48	1.6	1245	30	304	PW	47
	5	16	3.48	1.6	1550	30	304	PW	47
	5	18	3.88	1.2	1550	30	304	PW	58
	5	20	4.18	0.9	1550	30	304	PW	68
	4	16	4.75	1.6	1245	30	304	PW	56
	4	16	4.75	1.6	1245	30	316	PW	56
	4	16	4.75	1.6	1550	30	304	PW	56
	4	18	5.15	1.2	1245	30	304	PW	66
	4	18	5.15	1.2	1550	30	304	PW	66
	3	14	6.47	2	1245	30	304	LC	58
	3	14	6.47	2	1550	30	304	LC	58
	3	16	6.87	1.6	1245	30	304	LC	66
	3	16	6.87	1.6	1245	30	316	LC	66
	3	16	6.87	1.6	1550	30	304	LC	66
	3	12	8	2.5	1550	30	304	PW	58
	2	12	10.2	2.5	1245	30	316	LC	65
	2	14	10.7	2	1245	30	304	IC	71
	2	14	10.7	2	1245	30	316	IC	71
	2	14	10.7	2	1550	30	304	IC	71
	2	16	11.1	1.6	1245	30	316	IC	76
	1.6	10	12.88	3	1245	30	316	LC	66
	3.4	12	16.5	2.5	1245	30	316	IC	75
	1	10	22.25	3.15	1245	30	304	IC	77
	1	10	22.25	3.15	1245	30	316	IC	77
	1	10	22.25	3.15	1830	30	316	IC	77
	1	10	25	3.15	1600	30	304	IC	79
